eSim: Comprehensive EDA for Electronic Design

eSim is a free, open-source Electronic Design Automation (EDA) tool supporting the full design workflow. It integrates KiCad for schematic and PCB design, and Ngspice for circuit simulation, providing a powerful, cost-effective alternative to commercial software.

The platform handles analog and mixed-signal simulations. It includes tools for building custom Spice models and subcircuits. eSim is accessible on Ubuntu and Windows, with a cloud version available.

Key Features of eSim

1. Circuit Design: Draw schematics with KiCad and generate netlists.
2. Circuit Simulation: Perform analog and mixed-signal simulations using Ngspice.
3. PCB Layout: Design PCB layouts and generate Gerber files with KiCad.
4. Model Builder: Add and edit device models and subcircuits.
5. OS Support: Compatible with Ubuntu and Windows.

Ideal Use Cases for eSim

• Education and training in electronics design.
• Student projects and academic research.
• Hobbyist and maker prototyping.
• Cost-effective design for SMBs.
• Engineers seeking free EDA alternatives.
